Smart Card Security Code Reading for Part of Hyundai/Kia Models（46 chip）BY OBDSTAR X300 DP PLUS
1. the model with card slot;
2. the model with one-key start.
1. Specific method for 12digit code reading of the model with card slot(shown as Figure I): remove the card slot shell first (shown as Figure II). MINI ND900 cannot receive the vehicle signal directly for the limitation of card slot design, therefore it is necessary to remove the card slot to proceed. If the first time failed, please repeat for several times.
Note: When reading 12-digit code of the smart card, pls
remove the battery and then operate as above. After 12-digit code reading is successful, its display sequence is as follow: the last two digits in the second row + all digits in the first row, that is 63 4B 69 4D 82 52. Shown as below.
